Size: 18nch

RMS Power: 6000wrms

RMS Program: 15.000 - 20.000wrms 3sec

MAX Watt: 12000wmax

Cone: Paper many layers

Dust cap : Carbon FROM MADE IN EUROPE

Surround material: Foam

Voice coil bobbin:Aluminium

Voice coil made : MADE IN USA

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Nominal impedance:D0.5

Size: 18nch

RMS Power: 6000wrms

RMS Program: 15.000 - 20.000wrms 3sec

MAX Watt: 12000wmax

Cone: Paper many layers

Dust cap : Carbon FROM MADE IN EUROPE

Surround material: Foam

Voice coil bobbin:Aluminium

Voice coil made : MADE IN USA

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Nominal impedance:D0.7

Size: 18nch

RMS Power: 6000wrms

RMS Program: 15.000 - 20.000wrms 3sec

MAX Watt: 12000wmax

Cone: Paper many layers

Dust cap : Carbon FROM MADE IN EUROPE

Surround material: Foam

Voice coil bobbin:Aluminium

Voice coil made : MADE IN USA

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Nominal impedance:D1

Size: 21nch

Cone: Competition Grade paper

Surround material: Foam

Voice coil made : MADE IN USA or MADE IN GREECE

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Dust cap : Carbon FROM MADE IN EUROPE

Spider dimension : 4''ID / 10''OD

RMS Power: 6.500wrms

RMS Program: 18.000wrms

MAX Watt: 12.000wmax

Size: 21nch

Cone: Competition Grade paper

Surround material: Foam

Voice coil made : MADE IN USA or MADE IN GREECE

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Dust cap : Carbon FROM MADE IN EUROPE

Spider dimension : 4''ID / 10''OD

RMS Power: 6.500wrms

RMS Program: 18.000wrms

MAX Watt: 12.000wmax

Size: 21nch

Cone: Competition Grade paper

Surround material: Foam

Voice coil made : MADE IN USA or MADE IN GREECE

Voice coil dimension : 4.0inch

Voice coil layer: 8layer

Dust cap : Carbon FROM MADE IN EUROPE

Spider dimension : 4''ID / 10''OD

RMS Power: 6.500wrms

RMS Program: 18.000wrms

MAX Watt: 12.000wmax

Size: 12nch

Cone: Competition Grade paper

Surround material: Foam with FABRIC

Voice coil made : MADE IN USA

Voice coil dimension :4.0inch

Voice coil layer:8layer

Dust cap : Carbon FROM MADE IN EUROPE

Nominal impedance:dual 0.5ohm

Voice coil wire:aluminium

RMS Power: 4500wrms

MAX Watt: 9000wmax

Sensitivity: 91.2dB

Net weight: 32kg

Magnet dimension:Φ250*20mm 3PCS

Size: 15inch

Cone: Competition  Grade Paper

Surround material: Foam

Voice coil: 3.0inch

RMS Power: 2.000Watt

Sensitivity: 89.5dB

Resonance frequency(f0): 36.3Hz

Magnet Weight: 300Oz

Size: 15inch

Cone: Competition  Grade Paper

Surround material: Foam

Voice coil: 3.0inch

RMS Power: 2.000Watt

Sensitivity: 89.1dB

Resonance frequency(f0): 34.8Hz

Magnet Weight: 300Oz

• MODEL:TRF SW1545 D0.5
• Size: 15nch
• Cone: Competition Grade paper
• Surround material: Foam with FABRIC
• Voice coil made : MADE IN USA
• Voice coil dimension : 4.0inch
• Voice coil layer: 8layer
• Dust cap : Carbon FROM MADE IN EUROPE
• Nominal impedance:dual 0.5ohm
• Voice coil wire:aluminium
• Spider dimension : 4''ID / 10''OD
• Spider material : NOMEX
• Spider layers :2pcs x 4layers
• RMS Power: 4500wrms
• MAX Watt: 9000wmax
• Sensitivity: dB
• Resonance frequency(f0): - Hz
• Mechanical Q factor(Qms):
• Electrical Q factor(Qes):
• Total Q factor:(Qts):
• Xmax: mm
• Force factor: N/A
• Magnet Weight: -Oz
• Net weight: 33kg
• Basket:Die cast Alumium
• Magnet: Ferrite
• Magnet dimension:Φ250*20mm X 3PCS
• 1=Outer Dimension: 385mm - 15.16"
• 2=Mounting Depth: 273mm - 10.70"
• 3=Magnet Dimension: 256mm - 10.10"
• 4=Mounting Hole Dimension: 354mm - 13.94"

Size: 18nch

Cone: Competition Grade paper

Surround material: Foam with FABRIC

Voice coil made : MADE IN USA

Voice coil dimension :4.0inch

Voice coil layer:8layer

Dust cap : Carbon FROM MADE IN EUROPE

Nominal impedance:dual 1ohm

Voice coil wire:aluminium

RMS Power: 4500wrms

MAX Watt: 9000wmax

Net weight: 34kg

Magnet dimension:Φ250*20mm 3PCS

PAPER CONE

IMPEDANCE D2

POWER RMS 250W
MAX POWER 700W
VOICE COIL 2″
ΠΗΝΙΟ ΦΩΝΗΣ 4 ΣΤΡΩΣΕΩΝ
ΜΕ 1 ΔΙΠΛΑ SPIDER
ΜΑΓΝΗΤΗΣ ME 1 ΠΛΑΚΕΣ 20 x 156mm

SIZE: 12inch

CONE:competition grade paper

SURROUND MATERIAL:foam

VOICE COIL:2 inch

RMS POWER:350 WATT

SENSITIVITY:89.2db

MAX WATT:700wmaxx

RESORANCE FREQUENCY(fo):36.2Hz

MECHANICAL Q FACTOR(Qms):5.6

ELECTRICAL Q FACTOR(Qes):0.62

TOTAL Q FACTOR(Qts):0.56

X MAX:6 mm

FORCE FACTOR:13.6 N/A

MAGNET WEIGHT:50 oz

• ME PAPER CONE
• IMPEDANCE D2
• POWER RMS 250W
• MAX POWER 500W
• VOICE COIL 2″
• ΠΗΝΙΟ ΦΩΝΗΣ 4 ΣΤΡΩΣΕΩΝ
• ΜΕ 1 ΔΙΠΛΑ SPIDER
• ΜΑΓΝΗΤΗΣ ME 1 ΠΛΑΚΕΣ 20 x 156mm

SIZE:1Oinhc

CONE:Competition Grade Paper

SURROUND MATERIAL:Foam

VOICE COIL:2inch

RMS POWER:350Watt

SENSITIVITY:87.5db

MAX WATT:700wmaxx

RESORANCE FREQUENCY(fo):38.3Hz

MECHANICAL Q FACTOR(Qms):5.23

ELECTRICAL Q FACTOR(Ques):0.53

TOTAL Q FACTOR(Qts):0.48

X MAX:6mm

FORCE FACTOR:13.4 N/A

MAGNET WEIGHT:50 OZ
