160 Watts max
6.5″ high power midwoofer with anodized aluminum cone
6.5″ high power midwoofer
25 mm / 1″ voice coil
Black anodized aluminum cone
Nomex spider
Resonance free steel basket
High efficient 3 ohms version
Linearized motor
Incl. protection grill
Goldplated soldering terminal
1 paModel
High power midwoofer
Diameter
165 mm / 6.50"
Power Handling (RMS/max.)
110 / 160 Watts
Impedance
3 ohms
Efficiency
89 dB
Frequency Response
35 Hz – 4 kHz
Voice Coil
25 mm / 1"
Membran Layout
Black anodized aluminum
Mounting Ø
142.5 mm / 5.61"
Mounting Depth
68 mm / 2.68"
Resonance Frequency (Fs)
60.1 Hzir / package

ΠΕΡΙΣΣΟΤΕΡΕΣ ΠΛΗΡΟΦΟΡΙΕΣ

TS 20HR

White LED-Cone-Illumination
Chrome Basket
Magnet-Cover
incl. In-Line X-Over
Blade-Grilles




Μέγεθος: 13 cm
Αντίσταση (Ohm): 4
Ευαισθησία: No
Power (RMS): 75W
Power (Music): 150W
Διάμετρος Τρύπας: 118 mm
Βάθος Μεγαφώνου: 60 mm





Full Range







4"   128mm ,100 Watt, 87 db , 4Ω





NRSC Paper Cone ,Removable Mounting Flanges




Vented V.C Former & Magnet System





Τρύπα 90 mm , βάθος 53mm




The shallow mount profile speakers of the DSX SERIES are geared with specialized, concealed magnet motors. The ultra flat but with heavy duty 25 mm voice coils equipped well-sounding loudspeakers are the first choice in space-saving installations. As a result of their shallow installation depth they are perfectly suitable for all vehicles, where installation locations are rather limited or where factory speakers just need replacement.
DSX6.2E
16,5 cm (6.5") Component System

Specifications:100 Watts RMS, 200 Watts max.
Frequency Response 65 - 22000 Hz
Impedance 4 Ohms
Swiveling 25 mm Silk Dome Neodymium Tweeters
12 dB In-line Crossovers
Installation Opening 145 mm
Installation Depth 45 mm

ΠΕΡΙΣΣΟΤΕΡΕΣ ΠΛΗΡΟΦΟΡΙΕΣ

1300 Hz

ΠΕΡΙΣΣΟΤΕΡΕΣ ΠΛΗΡΟΦΟΡΙΕΣ

User’s manual

ΠΕΡΙΣΣΟΤΕΡΕΣ ΠΛΟΡΟΦΟΡΙΕΣ

2 way 6" speaker system

Specifications

RMS Power Handling: 80 watts per peaker
PEAK Power Handling: 180 Watts per Speaker // 360 Watts per System
Frequency Response: 65Hz - 20 kHz
SPL @ 1w/1m: 90dB
System Impedance: 4-Ohm
Mounting Depth 2.56" (6.5cm)
Size 6"

Features

2 way speaker system
25 mm Silk Dome Tweeter
Neodymium motor design ( tweeter )
Woven Kevlar Fiber cone
Hign Temperature Kapton voice coil former
Rubber surrounds
Intergraded crossover design
includes Custom Molded Grills

EMPHASER EM-BMWR1 - For the joy of listening to music Retrofitted in just a few minutes, this high-end coaxial system transforms your BMW or MINI into a rolling concert hall.   The plug & play center speaker EM-BMWC1 is compatible with various BMW models. It is a perfect complement to the two vehicle-specific EMPHASER speakers EM-BMWF1 (compo) and EM- BMWR1 (coaxial). The EM-BMWC1 fits perfectly into the original installation opening in the dashboard and impresses with its fascinating sound and places in a fantastic way the music happening directly on the dashboard. With 40 watts total power, the 10 cm /4″ 2-way center speaker always plays sovereign - whether with the original radio or with an amplifier. The aluminum membrane with its fast impulse response is the guarantor for the high precision of the EM-BMWC1. The diaphragm is driven by a powerful neodymium magnet with 1″ voice coil, is encased in a durable rubber surround and has a centering spider perfectly matched to the system. The 16 mm tweeter with fabric dome shines with high resolution and fine details and is mounted practical inward offset. The torsion-resistant aluminum basket ensures high impulse fidelity, especially in the fine vibrations in the midrange. The scope of delivery includes a high-pass crossover (150 Hz / 6 dB) that filters out the bass and thus enables distortion-free reproduction, especially at high volumes. The vehicle-specific connection terminal on the crossover ensures a secure connection. Main Features: 10 cm 2-way coaxial system compatible with BMW and Mini vehicles vehicle specific connections Aluminum diaphragm Aluminum die-cast basket durable Connex center spider and rubber surround 16 mm tweeter with fabric dome tweeter switchable 150 Hz/6 dB highpass filter Technical specifications: Rated power: 25 W RMS Frequency response: 150 Hz - 22 kHz Nominal impedance: 4 Ohm Sensitivity: 90 dB Scope of delivery: 1 piece center speaker 1 piece crossover

The QUANTUM QXE6.2TV2 silk dome neodymium tweeter as a V2 version is also a completely new development. A look at the measurement protocol reveals the potential of this extremely good 25 mm neodymium tweeter: This shows a frequency response that looks as if it had been drawn with a ruler! Incredibly linear up to well over 22,000 Hz, this tweeter plays with absolute confidence and playful ease. The grille can be unscrewed together with the housing using a metric thread and significantly reduces the space required (e.g. for the mirror triangle). A housing made of ABS is included in the scope of delivery for surface use. Including 6 dB cable crossover.
Specifications
25 mm (1") Silk Dome Neodymium Tweeters
Power Rating 125 Watt/RMS, 250 Watt/Max.
Frequency Range 3500 - 24000 Hz
Impedance 4 Ω
Screwable Tweeter Brackets for flexible Installation
Built-in and Surface Mount Housings
6 dB Cable Crossovers
Installation depth 9 mm
Installation diameter 44 mm



Ultimate Car Audio by JBL

Τα ηχεία της σειράς Stadium της JBL – διαθέσιμα σε 2″, 3″, 5-1/4″, 6-1/2″, 6″ x 8″, 4″ x 6″, 6″ x 9″ και 3/4″ – φέρνουν τον εμβληματικό ήχο JBL που μπορεί να προέλθει μόνο από μια γενεαλογία 75 ετών αριστείας ήχου σε σχεδόν οποιοδήποτε αυτοκίνητο στο δρόμο.
Τα Stadium’s Plus One™ fiberglass woofers προσφέρουν μπάσα υψηλής απόδοσης, βαθιά και στιβαρά.
Τα υφασμάτινα tweeter με θόλο υψηλής ανάλυσης 3/4″ προσφέρουν υψηλές ταχύτητες έως και 40 kHz. Διατίθενται μεσαίες κατηγορίες 2″ και 3″ για την αναβάθμιση two-way συστημάτων εξαρτημάτων σε three-way.
Τα συμπαγή ηχεία μεσαίας κατηγορίας 3″ προσφέρουν επίσης μια τέλεια λύση plug-and-play με απόκριση χαμηλής συχνότητας στα 300 Hz και υψηλή ευαισθησία.

---

General Specifications

3/4" (19mm) Edge-Driven Aluminum Dome Tweeter

• Power Handling: 50Wrms, 150W peak


• Sensitivity (@ 2.83V): 93dB


• Frequency Response: 2kHz – 40kHz


• Impedance: 3.0 ohms


• Gross weight: 0.306kg

---
